Data Acquisition System
SIRIUS
The world's most versatile USB and EtherCAT data acquisition system. Any signal, any sensor, packed with cutting edge technology.
Main Features
❖ Usb / Ethercat Interface: SIRIUS DAQ system can be connected via USB or EtherCAT to any Windows compatible PC or to one of our high-performance SBOX data loggers.
❖ Any Sensor: Array of different amplifiers are available that can acquire data from virtually any sensor on the market. IEPE, voltage, high voltage, charge, full/half/quarter bridge, LVDT, RTD, thermocouples, current, resistance, counter, encoder, and digital inputs are available.
❖ Universal Analog Inputs: Universal analog amplifiers can accept voltage and full/half/quarter bridge signals natively as well as IEPE, charge, thermocouples, RTD, current, resistance, and LVDT signals with the use of DSI adapters.
❖ 160 dB Dynamic Range: Our DualCoreADC® technology boosts dual 24-bit delta-sigma ADC's with an anti-aliasing filter on each analog channel, achieving astonishing 160 dB dynamic range in time and frequency domain with 200 kHz sampling rate per channel.
❖ 1 MHz Sampling Rate: A combination of software and hardware allows for acquisition speeds up to 1 MHz per channel on SIRIUS HS devices with real-time data processing and streaming to disk.
❖ High Isolation: High channel-to-channel and channel-to-ground isolation prevents damage to the systems from excessive voltage and avoids ground loops.
❖ Flexible And Scalable: SIRIUS DAQ system can grow with your needs. You can start with a single channel and scale the system to thousands of channels at any time.
❖ Sensor Power Supply: Amplifiers provide channel-independent, programmable power supply for sensor excitation.
❖ Digital / Counter / Encoder Inputs: Each channel is capable of 3x digital inputs, 1x event counter, encoder, period, pulse-width, duty-cycle, and precise frequency and angle measurement using patented SUPERCOUNTER® technology.
❖ Isolated Can Input: High speed CAN 2.0b channels with 1 Mbit/sec data throughput with additional support for CCP, OBDII, J1939, and CAN output.
❖ Analog Outputs / Function Generator: SIRIUS slice can be configured with 8 analog outputs which can also function as a multi-channel function generator (software option upgrade required), analog replay, or control device with the output voltage signal of ±10V.
❖ Fully Synchronized: Each channel, analog, digital, or CAN is synchronized with microsecond accuracy.
SBOX
Highly reliable SSD data logger with powerful data processing computer. The perfect companion to SIRIUS data acquisition system.
Main Features
❖ Highly Reliable Ssd Storage: SBOX provides highly reliable data recording with typical 180 MB per second write speed straight into built-in fast SSD drive. SSD drive is removable so you can swap and replace it quickly.
❖ High-Performance Data Processing Computer: With 8-thread Intel Core i7 CPU and 8GB memory, SBOX is also an extremely powerful computer for worry-free, real-time data processing.
❖ 6 Usb Interfaces: SBOX includes four USB3.0 ports and two USB2.0 ports. All USB ports feature screw-lock connectors.
❖ 3 Network Interfaces: Two gigabit LAN ports and wireless WLAN interface with external antenna ensure maximum connectivity.
❖ Ethercat Interface: Built-in EtherCAT interface port with synchronization for USB and EtherCAT DAQ devices like SIRIUS and KRYPTON.
❖ 100 Hz Gps With RTK: Optional 10Hz or 100Hz GPS receiver with additional RTK support can be built straight into SBOX.
R1DB / R2DB
Compact, mobile data acquisition system with a built-in data logger, powerful data processing computer, multi-touch display, and internal batteries for maximum portability.
Main Features
❖ High-End Signal Conditioning: R1DB/R2DB data acquisition system is built around SIRIUS DAQ technology and features the same versatile and powerful amplifiers for world-leading signal conditioning. See SIRIUS product page for detailed SIRIUS DAQ technology overview.
❖ All-in-One Instrument: R1DB/R2DB instruments are stand-alone DAQ systems with the built-in touchscreen LED display, powerful data processing computer, SSD data logging capabilities, and internal Li-Ion batteries (R1DB/R2DB). A version without battery is also available (R2D).
❖ Up To 32 Analog Inputs: Systems can be configured with one (R1DB) or two (R2DB) SIRIUS DAQ slices for the total of 32 analog inputs capable of connecting virtually any sensor.
❖ Up To 16 Counter / Encoder Inputs: Up to 16 counter/encoder or 48 digital input channels, all equipped with our patented SUPERCOUNTER® technology.
❖ Up To 2 Isolated Can Ports: Up to 2 high speed CAN 2.0b channels with 1 Mbit / sec data throughput with additional support for CCP, OBDII, J1939, and CAN output.
❖ Ethercat Port: DAQ system includes EtherCAT master port with built-in synchronization for easy connection and extension of any of our EtherCAT based DAQ system like KRYPTON DAQ modules.
❖ All Interfaces: Interfaces for Wireless LAN, dual GLAN, 4x USB 3.0, GPS, HDMI, 2x synchronization are available.
❖ 100 Hz GPS with RTK: Optional 10Hz or 100Hz GPS receiver with additional RTK support can be built right into R1DB/R2DB DAQ system.
R3
Rack mountable DAQ system built into standard PC computer chassis and integrated SIRIUS data acquisition slices. Ready for simple and inexpensive upgrade of PC components.
Main Features
❖ High-End Signal Conditioning: R3 data acquisition system is built around SIRIUS DAQ technology and features the same versatile and powerful amplifiers for world-leading signal conditioning.
❖ Up To 48 Analog Inputs: R3 can be configured with up to three SIRIUS DAQ slices for a total of 32 analog inputs for virtually any sensor.
❖ Up To 24 Counter / Encoder Inputs: Up to 16 counter/encoder or 48 digital input channels, all equipped with our patented SUPERCOUNTER technology.
❖ Up To 3 Isolated Can Ports: Up to 3 high speed CAN 2.0b channels with 1 Mbit/sec data throughput with additional support for CCP, OBDII, J1939, and CAN output.
❖ High-Performance Computer: PC computer inside is built with standard off the shelf computer components which allows easy upgrade of hard-drive, memory, CPU, and other components.
❖ 19'' Rack Mountable: The included PC chassis can be mounted in any 19'' rack cabinet.
❖ Sensor Power Supply: Each channel provides power for sensor excitation.
❖ Digital / Counter / Encoder Inputs: Each channel is capable of 3x digital inputs, 1x event counter, encoder, period, pulse-width, duty-cycle. Precise frequency and angle measurement use patented SUPERCOUNTER® technology.
❖ Fully Synchronized: Each channel, either analog, digital or CAN is synchronized with microsecond accuracy.
R4
Compact data acquisition system with up to 64 analog inputs, 32 counter inputs and 32 analog outputs with built-in high-performance, highly reliable data processing computer and SSD data logger.
Main Features
❖ High-End Signal Conditioning: R4 data acquisition systems are built around SIRIUS DAQ technology and feature the same versatile and powerful amplifiers for world-leading signal conditioning. Visit SIRIUS product page for detailed SIRIUS DAQ technology overview.
❖ Powerful And Reliable Computer: R4 DAQ system offers powerful built-in data processing computer and fast and reliable SSD data logging capabilities for a stand-alone operation.
❖ Up To 64 Analog Inputs: System can be configured with up to 4 SIRIUS DAQ slices for a total of 64 analog inputs for connecting virtually any sensor.
❖ Up To 32 Counter / Encoder Inputs: System can hold up to 32 counter/encoder inputs or 96 digital input channels, all equipped with our patented SUPERCOUNTER® technology.
❖ Up To 4 Isolated Can Ports: Configure up to 4 high speed CAN 2.0b channels with 1 Mbit/sec data throughput with additional support for CCP, OBDII, J1939, and CAN output.
❖ Ethercat Master Port: R8 DAQ systems include EtherCAT master port with built-in synchronization for easy connection and extension of any of our EtherCAT based DAQ system like KRYPTON DAQ modules or SIRIUS DAQ system.
❖ All Interfaces: Interfaces for Wireless LAN, dual GLAN, 4x USB 3.0, GPS, HDMI, 2x synchronization are available.
❖ 100 Hz GPS with RTK: Optional 10Hz or 100Hz GPS receiver with additional RTK support can be built straight into R4 DAQ system.
R8
High channel count data acquisition system with built-in data logger and powerful data processing computer, touch screen display (R8D) and internal batteries (R8B, R8DB) for maximum portability.
Main Features
❖ High-End Signal Conditioning: R8 data acquisition systems are built around SIRIUS DAQ technology and feature the same versatile and powerful amplifiers for world-leading signal conditioning. Visit SIRIUS product page for detailed SIRIUS DAQ technology overview.
❖ All-in-One Instrument: R8 instruments are high channel count, standalone DAQ systems with built-in powerful data processing computer, SSD data logging capabilities, touch-screen LED display (R8D and R8DB), and internal Li-Ion batteries (R8B/R8DB) for maximum portability.
❖ Up to 128 Analog Inputs: Systems can be configured with up to eight SIRIUS DAQ slices for a total of 128 analog inputs for virtually any sensor.
❖ Up To 64 Counter / Encoder Inputs: R8 DAQ system can be configured with up to 64 counter / encoder or 192 digital input channels, all equipped with our patented SUPERCOUNTER® technology.
❖ Up To 8 Isolated Can Ports: Configure up to 8 high speed CAN 2.0b channels with 1 Mbit/sec data throughput with additional support for CCP, OBDII, J1939, and CAN output.
❖ Up to 64 Analog Outputs: R8/R8B can be configured with up to 64 analog outputs and can function as a multi-channel function generator, analog replay, or control device with the output voltage signal of ±10V.
❖ Ethercat Master Port: R8 DAQ systems include an EtherCAT master port with built-in synchronization for easy connection and extension of any of our EtherCAT based DAQ system like KRYPTON DAQ modules or SIRIUS DAQ system.
❖ All Interfaces: Interfaces for Wireless LAN, dual GLAN, 4x USB 3.0, GPS, HDMI, 2x synchronization are available.
❖ 100 Hz GPS with RTK: Optional 10Hz or 100Hz GPS receiver with additional RTK support can be built straight into R1DB/R2DB DAQ system.
MINITAURs
Mixed signal data acquisition system and multichannel data logger with cutting-edge technology at an attractive price.
Main Features
❖ All-in-One Device: Instrument packs powerful data logger and data acquisition device in one compact chassis. Inside this small instrument lives a powerful Intel Core i3 CPU computer, solid state drive, WiFi, two LAN ports, four USB 3.0 and two USB 2.0 ports, EtherCAT master port, and optional 10 Hz or 100 Hz GPS receiver.
❖ Universal Analog Inputs: Instrument can accept voltage and full / half / quarter bridge signals natively as well as IEPE, charge, thermocouples, RTD, current, resistance and LVDT signals with the use of DSI adapters.
❖ 160 dB Dynamic Range: With our DualCoreADC® technology all analog inputs boost dual 24-bit delta-sigma with the anti-aliasing filter, achieving astonishing 160 dB dynamic range in time and frequency domain.
❖ Sensor Power Supply: Amplifiers provide channel-independent, programmable sensor power supply.
❖ Digital / Counter / Encoder Inputs: Each channel is capable of 3x digital inputs, 1x event counter, encoder, period, pulse-width, duty-cycle. Precise frequency and angle measurement use patented SUPERCOUNTER® technology.
❖ Isolated Can Input: High speed CAN 2.0b channels with 1 Mbit / sec data throughput with additional support for CCP, OBDII, J1939, and CAN output.
❖ Fully Synchronized: Each channel, analog, digital or CAN is synchronized with microsecond accuracy.
DEWE-43A
Award-winning versatile USB data acquisition system with unmatched price/performance ratio and a small footprint.
Main Features
❖ Universal Analog Inputs: SIRIUS mini is our smallest, 4-channel data acquisition system, mainly suitable for acoustic, vibration, and angle measurements.
❖ Sensor Power Supply: Each channel provides power for sensor excitation.
❖ Counter / Encoder / Digital Inputs: Each channel is capable of 3x digital inputs, 1x event counter, encoder, period, pulse-width, duty-cycle. Precise frequency and angle measurement use patented SUPERCOUNTER® technology.
❖ Isolated Can Inputs: High speed CAN 2.0b channels with 1 Mbit/sec data throughput with additional support for CCP, OBDII, J1939, and CAN output.
❖ Fully Synchronized: Each channel, either analog, digital or CAN is synchronized with microsecond accuracy.
❖ Isolated Power Supply: DEWE-43A power supply is internally isolated eliminating the possibility of ground loops.
SIRIUS MINI
Small and highly portable, USB powered data acquisition system ideal for acoustic, vibration, and rotating machinery analysis.
Main Features
❖ Smallest DAQ: SIRIUS mini is our smallest, 4-channel data acquisition system, mainly suitable for acoustic, vibration, and angle measurements.
❖ Unmatched Price: SIRIUS mini ships off-the-shelf with high-quality signal conditioning and world-leading, award-winning data acquisition software for the best price on the market.
❖ USB Powered: SIRIUS mini does not require any external power supply. It can be powered straight from USB connection, for example, a laptop.
❖ 4 IEPE / Voltage Inputs: System is configured with 4 high dynamic analog inputs, dual sigma-delta ADC's with 200 kHz per channel sampling rate and up to 160 dB dynamic range.
❖ Counter / Encoder / Digital Inputs: System is configured with one counter/encoder input and is capable of 3x digital inputs, 1x event counter, encoder, period, pulse-width, duty-cycle. Precise frequency and angle measurement use patented SUPERCOUNTER® technology.
